C-axis parameters
|
| Table diameter | 140mm |
| Countertop bearing capacity | 30kg |
| Rated torque of C-axis | 20Nm
|
| C-axis rated speed | 200rpm |
| C-axis rotation range | 士360° |
| C-axis encoder type | absolute |
| C-axis positioning accuracy | 8"VDI3441
|
| C-axis repeated positioning accuracy | 4"VDI3441 |
A-axis parameters
|
| A-axis rated torque | 200Nm |
| A-axis rated speed | 150rpm |
A-axis tightening torque
| 2000(60bar)Nm |
| A-axis rotation range | ±110° |
| A-axis encoder type | absolute |
| A-axis positioning accuracy | 8"VDI3441 |
| A-axis repeated positioning accuracy | 4"VDI3441
|
| Total weight | 245kg
|
